Built for demanding high-pressure applications, the NEWTOP NTWP30CI delivers powerful water transfer with excellent structural stability and long-term durability. Its cast-iron centrifugal system, reinforced engine construction, and smooth operating characteristics ensure dependable performance across irrigation, drainage, firefighting support, and other heavy-duty field tasks.
The NEWTOP NTWP30CI is equipped with a robust cast-iron centrifugal pump engineered for superior hydraulic performance. Its 208 mm precision-machined cast-iron impeller ensures strong lift height, stable discharge pressure, and efficient flow consistency, making it ideal for applications that require sustained high-pressure output.
At its core, the pump is powered by a NEWTOP 190F gasoline engine featuring 42CrMo forged steel crankshaft and camshaft components, delivering smooth torque and long service life. The patented cylinder design enhances thermal efficiency while keeping fuel consumption under control. A reinforced engine casing helps the unit resist shock and vibration, while rigorous endurance testing ensures reliable operation in harsh environments ranging from –5 °C to 45 °C.
To further improve stability, the NTWP30CI adopts a purpose-built full-frame structure with a dedicated damping system that significantly reduces working vibration. Its easy-start mechanism, simple maintenance design, and reliable cast-iron construction make it a durable solution for agricultural irrigation, emergency flood drainage, household water supply, marine use, and firefighting assistance. These qualities make it a dependable option for gasoline water pump suppliers and outdoor power equipment dealers seeking a high-lift, high-performance pumping solution.
| Inlet Size | 80mm(3") |
|---|---|
| Outlet Size | 80mm(3") |
| Max. flow | 40m³/h |
| Lift Height | 92m |
| Suction Lift | 6m |
| Pump Type | Centrifugal Pump |
| Material of Impeller | 208mm Cast Iron Impeller |
| Material of Pump body | Cast iron |
| Engine Model | 190F |
| Engine Type | Single cylinder,Air cooling,4 stroke,OHV |
| Bore x Stroke(mm) | 90x66 |
| Compression Ratio | 8.5:1 |
| Max. Output | 15hp |
| Max.Torque | 26N.m |
| Displacement | 420cc |
| Material of Crankshaft | Drop-froging Steel |
| Material of Camshaft | Drop-froging Steel |
| Fuel Consumption(g/kw.h) | ≤370 |
| Starting Type | Manaul |
| Fuel Tank Capacity | 6.5L |
| Oil Capacity | 1.1L |
