Designed for operators facing higher-volume and higher-pressure needs, the NEWTOP NTDWP30H delivers strong lift, dependable discharge performance and diesel-powered durability. It is well-suited for demanding sites that require reliable pressure stability over extended use.
The NEWTOP NTDWP30H integrates diesel reliability with a high-pressure centrifugal design to handle larger discharge requirements. Its hydraulic-optimized pump body ensures excellent lift and consistent pressure output, even during extended pumping cycles.
A forged 42CrMo crankshaft, durable nitrided gears and reinforced engine housing contribute to long service life, reduced vibration and stable power delivery. The strong full-frame structure further increases stability during high-load applications.
This model is ideal for agricultural irrigation, large-scale drainage tasks, emergency firefighting support, construction water supply and various field operations requiring both high lift and resilient performance.
| Suction/Discharger Port Diameter(mm (in)) | 80(3") |
|---|---|
| Max. Discharge capacity(m³/h) | 40 |
| Max.head lift(m) | 78 |
| Self-priming Time(s/4m) | 220 |
| Max suction head(m) | 8 |
| Rotation speed(rpm) | 3600 |
| Noise level(dB(A)/7m)) | 85 |
| Engine model | NTDE192F |
| Rated Power(kW) | 8.2 |
| Fuel consumption(g/kW.h) | 310 |
| Displacement(cc) | 498 |
| Starter system | Manual |
| Fuel tank capacity(L) | 5.5 |
| Continuous working period(Hours) | 2.6 |
