As a higher-capacity model in the NEWTOP lineup, the NTGR10500 outputs a powerful 10 kW to accommodate larger electrical loads. Its heavy-duty engine construction, forged crankshaft, and copper-winding alternator contribute to stable long-term performance. Designed for extended use with a 40 L tank, this generator supports intensive industrial operations, large commercial facilities, and high-demand emergency power situations.
Equipped with an 18 hp OHV engine, the NTGR10500 features drop-forged steel components for high structural integrity and long service life under sustained workloads.
The patented cylinder design improves combustion efficiency and reduces fuel waste, enabling stable output at high loads.
A strong steel frame and optimized anti-vibration mounts ensure smooth running, particularly valuable in industrial and construction settings.
The SENCI 100% copper-wire alternator produces high-quality electricity with excellent overload tolerance.
Safety systems include low-oil alerts, short-circuit protection, and stable voltage regulation.
Its extra-large 40 L fuel tank provides extended runtime, supporting uses ranging from commercial power supply to emergency standby and field operations.
| Voltage | 110-127V,220-240V |
|---|---|
| Frequency | 50HZ,60HZ |
| AC Rated Output | 10kW |
| AC Max Output | 10.5kW |
| DC Voltage/ Amperage | 12V 8.3A |
| Phase | Single or Three |
| Generator Type | Synchronization, Brush. SENCI copper wire |
| Engine Model | 196F |
| Engine Type | Single cylinder,Air cooling,4 stroke,OHV |
| Bore x Stroke(mm) | 96x86 |
| Compression Ratio | 8.6:1 |
| Max. Output | 18hp |
| Displacement | 520cc |
| Fuel Consumption(g/kw.h) | ≤370 |
| Starting Type | Electric |
| Material of Crankshaft | Drop-froging Steel |
| Camshaft | Drop-froging Steel |
| Fuel Tank Capacity | 40L |
